Observing ADK Agents: OpenTelemetry Tracing with Jaeger

November 18, 2025 · 7 min read

Google ADK Training

You build an AI agent with Google ADK. It works. But when you ask "Why did the agent choose that tool?" or "Which LLM call took 5 seconds?" – you're flying blind.

Enter distributed tracing: Jaeger visualizes every step your agent takes, from reasoning to tool execution to LLM calls. ADK has built-in OpenTelemetry support, making this a breeze... once you understand one crucial gotcha.

This post shows you the complete picture: what to do, why it matters, and the one thing that trips up most developers.

Jaeger UI showing traces from an ADK agent

The Problem We're Solving

Your agent runs. But where does the time go?

Input: "What is 123 + 456?"
│
├─ Agent reasoning (planning which tool)    ⏱️ 0.5s
├─ LLM call to Gemini                       ⏱️ 1.2s
├─ Tool execution (add_numbers)             ⏱️ 0.1s
├─ Final response generation                ⏱️ 0.8s
│
Output: "579"

Without tracing, you never see this breakdown. With Jaeger, you get a flame graph showing every millisecond.

Quick Start: 5 Minutes

1. Start Jaeger (Docker)

docker run -d --name jaeger \
  -e COLLECTOR_OTLP_ENABLED=true \
  -p 16686:16686 -p 4318:4318 \
  jaegertracing/all-in-one:latest

2. Install Dependencies

pip install google-adk opentelemetry-sdk \
  opentelemetry-exporter-otlp-proto-http

3. Copy the Tutorial

cd til_opentelemetry_jaeger_20251118
make setup
cp .env.example .env  # Add GOOGLE_GENAI_API_KEY

4. Run and Observe

make demo                # See traces exported automatically

5. View in Jaeger

Open http://localhost:16686 → Select google-adk-math-agent → Click "Find Traces"

You now have complete observability. That's it.

The Real Challenge: TracerProvider Conflicts

Here's where most developers get stuck:

❌ This Doesn't Work (With `adk web`)

from opentelemetry.sdk.trace import TracerProvider
from opentelemetry import trace

# You manually create a provider
provider = TracerProvider()
# ... add your exporter ...
trace.set_tracer_provider(provider)

# Meanwhile, adk web already started and:
# 1. Started FastAPI server
# 2. Initialized its own TracerProvider
# 3. Now your set_tracer_provider() call fails silently

# Result: Your custom exporter never gets used ❌

Why? OpenTelemetry enforces: "One global TracerProvider per process." ADK initializes first (in adk web mode), so you can't override it. Your exporter gets ignored, and traces never reach Jaeger.

✅ The Solution: Environment Variables

Instead of fighting for control, let ADK initialize everything:

# Set these environment variables
export OTEL_SERVICE_NAME=google-adk-math-agent
export OTEL_EXPORTER_OTLP_ENDPOINT=http://localhost:4318
export OTEL_EXPORTER_OTLP_PROTOCOL=http/protobuf

# Now start adk web - it reads env vars and configures OTel automatically
adk web .

In your agent code, just set the same env vars in your config:

import os

os.environ.setdefault("OTEL_SERVICE_NAME", "google-adk-math-agent")
os.environ.setdefault("OTEL_EXPORTER_OTLP_ENDPOINT", "http://localhost:4318")
os.environ.setdefault("OTEL_EXPORTER_OTLP_PROTOCOL", "http/protobuf")

# ADK (v1.17.0+) reads these and configures everything
# Your code runs on top of ADK's already-initialized provider
# No conflicts! ✓

This is the recommended approach in ADK v1.17.0+.

Alternative: Manual Setup (For Standalone Scripts)

If you're not using adk web, you have full control:

from opentelemetry.sdk.trace import TracerProvider
from opentelemetry.sdk.trace.export import BatchSpanProcessor
from opentelemetry.exporter.otlp.proto.http.trace_exporter import OTLPSpanExporter
from opentelemetry import trace

# Initialize FIRST (before any ADK imports)
provider = TracerProvider()
processor = BatchSpanProcessor(
    OTLPSpanExporter(endpoint="http://localhost:4318/v1/traces")
)
provider.add_span_processor(processor)
trace.set_tracer_provider(provider)

# NOW import ADK (uses your provider)
from google.adk.agents import Agent
# ... rest of your agent code ...

Why this works: You control initialization order. Provider is set before ADK runs.

When to use this: Standalone scripts, custom sampling, or detailed control over span processors.

What You Get in Jaeger

When you query google-adk-math-agent in Jaeger, you see:

Invocation (root)
├─ invoke_agent
│  ├─ call_llm (user question)
│  │  └─ 🕐 1.2s ← Gemini API latency
│  ├─ execute_tool (add_numbers)
│  │  └─ result: 579
│  └─ call_llm (final response)
│     └─ 🕐 0.8s
└─ SUCCESS ✓

Each span includes:

Exact timing (microsecond precision)
Tool inputs/outputs (what arguments were passed)
LLM prompts and responses (if not redacted)
Error traces (if something failed)

This is invaluable for debugging:

"Why did the agent pick the wrong tool?" → See the LLM reasoning
"Why is my system slow?" → Flame graph shows the bottleneck
"Did the tool actually run?" → See the span execution timing

Production: Google Cloud Trace

When running ADK on Google Cloud, you can export traces directly to Google Cloud Trace (part of Google Cloud Observability). This is the recommended approach for production deployments.

Why Google Cloud Trace?

Native Integration: No third-party infrastructure needed
Same OpenTelemetry: Uses the same OTLP protocol as Jaeger
Integrated Dashboard: View traces alongside logs and metrics in Cloud Console
Cost Effective: Pay only for what you use, with free tier available
Enterprise Ready: IAM controls, audit logging, compliance features

Setup for Google Cloud Trace

First, enable the required APIs:

gcloud services enable \
  aiplatform.googleapis.com \
  telemetry.googleapis.com \
  cloudtrace.googleapis.com \
  logging.googleapis.com \
  monitoring.googleapis.com

Install the Google Cloud exporters:

pip install google-adk \
  opentelemetry-sdk \
  opentelemetry-exporter-otlp-proto-grpc \
  opentelemetry-exporter-gcp-logging \
  opentelemetry-exporter-gcp-monitoring \
  opentelemetry-instrumentation-google-genai \
  opentelemetry-instrumentation-vertexai

Configure in your agent initialization (with adk web or standalone):

import os
from google.auth import default
from opentelemetry.sdk.trace import TracerProvider
from opentelemetry.sdk.trace.export import BatchSpanProcessor
from opentelemetry.exporter.otlp.proto.grpc.trace_exporter import OTLPSpanExporter
from opentelemetry.sdk.resources import Resource
from opentelemetry import trace

# Get your Google Cloud project ID
credentials, project_id = default()

# Create resource with project metadata
resource = Resource.create(
    attributes={
        "service.name": "adk-agent",
        "gcp.project_id": project_id,
    }
)

# Configure OTLP exporter for Google Cloud Trace
provider = TracerProvider(resource=resource)
otlp_exporter = OTLPSpanExporter(
    endpoint="telemetry.googleapis.com:443",
    credentials=credentials,
)
provider.add_span_processor(BatchSpanProcessor(otlp_exporter))
trace.set_tracer_provider(provider)

# Now initialize your ADK agent
from google.adk.agents import Agent
# ... rest of your agent code ...

Or use environment variables with adk web:

export OTEL_SERVICE_NAME=adk-agent
export OTEL_EXPORTER_OTLP_ENDPOINT=https://telemetry.googleapis.com:443
export OTEL_EXPORTER_OTLP_PROTOCOL=grpc
export GOOGLE_CLOUD_PROJECT=$PROJECT_ID

adk web .

View Traces in Google Cloud Console

# Open Cloud Trace UI directly
gcloud compute ssh --zone=us-central1-a instance-name -- \
  'curl http://localhost:8080' &

# Or navigate to Cloud Console:
# https://console.cloud.google.com/traces/

In the Cloud Trace Explorer:

Select your service name (adk-agent)
Filter by span name: call_llm, execute_tool, etc.
View traces with microsecond precision
Click "GenAI" tab to see LLM events, tool calls, and reasoning

Access Control

Grant these IAM roles to users who need to view traces:

# For viewing traces
gcloud projects add-iam-policy-binding $PROJECT_ID \
  --member=user:EMAIL \
  --role=roles/cloudtrace.user

# For writing traces (service account)
gcloud projects add-iam-policy-binding $PROJECT_ID \
  --member=serviceAccount:SA_EMAIL \
  --role=roles/telemetry.tracesWriter

For complete details, see the official ADK OpenTelemetry Instrumentation Guide.

Deployment Options: Local vs Cloud

Scenario	Backend	Setup
Local dev with `adk web`	Jaeger	Env vars
Standalone script	Jaeger	Manual setup
Production (Google Cloud)	Cloud Trace	Env vars
Custom sampling	Jaeger	Manual

Common Issues

Q: Traces not appearing in Jaeger?
A: Check Jaeger is running (docker ps), and verify OTEL_EXPORTER_OTLP_ENDPOINT=http://localhost:4318

Q: I see warnings about "Overriding TracerProvider"?
A: You're using manual setup with adk web. Switch to environment variables instead.

Q: Traces not appearing in Google Cloud Trace?
A: Verify your service account has roles/telemetry.tracesWriter. Check that the GOOGLE_APPLICATION_CREDENTIALS environment variable points to a valid service account JSON file.

Q: "Permission denied" error with Google Cloud Trace?
A: Ensure Telemetry API is enabled: gcloud services enable telemetry.googleapis.com. Also verify the service account has the correct IAM role.

Q: Can I use this in production?
A: Yes. Export to Google Cloud Trace (recommended for GCP), Honeycomb, Datadog, or any OTLP-compatible backend by changing the endpoint.

The Real Tutorial

This blog post is the high-level "why." For the complete working example with tests, see:

📚 OpenTelemetry + ADK + Jaeger Tutorial

42 unit tests
Both approaches demonstrated
Production-ready configuration
Makefile automation
Troubleshooting guide

Summary

✓ ADK has excellent OTel support out of the box
✓ Use environment variables for adk web mode (no conflicts)
✓ Use manual setup for standalone scripts (full control)
✓ Jaeger visualizes everything: reasoning, LLM calls, tool execution
✓ Works locally and in production (change the endpoint)

The "black box" of AI agents becomes fully observable. Debug with confidence.

Happy tracing! 🔍
